AT85C51SND3Bx
Parallel Slave Interface
The AT85C51SND3Bx implement a Parallel Slave Interface (PSI) allowing parallel con-
nection with a host for remote control and data transfer. By using this interface, the
AT85C51SND3Bx can be seen as a multimedia co-processor and be remotely con-
trolled by the host.
The main features of the PSI Interface are:
•
•
•
•
•
ARM / I80 glueless interface capability
8-bit parallel data bus
1-bit address bus
16-byte FIFO with MCU interrupt capability
Bi-directional multimedia bus connection through one DFC Channel
Figure 98 shows a typical PSI host connection. Interface consists in a 8-bit data bus, a
1-bit address bus and read and write signals along with a chip select.
Figure 98. Typical PSI Host Connection
HOST
AT85C51SND3B
D7:0
RD
SD7:0
SRD
SWR
SA0
WR
A0
CSx
INTx
SCS
Px.y
(1)
Note:
1. Optional signal for slave to host signaling.
Description
The C51 core interfaces with the PSI using the following Special Function Registers:
PSICON (see Table 231) the control register, PSISTA (see Table 232) the status regis-
ter, PSIDAT (see Table 233) the data register and PSISTH (see Table 234) the host
status register.
The PSI is enabled by setting the PSEN bit in PSICON.
As soon as the PSI is enabled, I/O ports are programmed in input and I/O pull-ups are
disabled.
Figure 99. PSI Block Diagram
PER
CLOCK
SWR
Control
Manager
SRD
SCS
SA0
Slave
Decoder
Interrupt
Controller
16-byte FIFO
CPU
Bus
Data
Manager
SD7:0
DFC
Bus
PSI
Interrupt
Request
207
7632A–MP3–03/06
