APL3512
Operating Waveforms
The test condition is VIN=5V, TA= 25oC unless otherwise specified.
Power On
Power Off
VIN
VIN
1
2
1
VOUT
VOUT
2
IOUT
IOUT
3
3
VIN =5V, RLOAD =30W, CIN =1mF/MLCC,
COUT =100mF/Electrolytic, SS open
VIN =5V, RLOAD =30W, CIN =1mF/MLCC,
COUT =100mF/Electrolytic, SS open
CH1: VIN, 2V/Div, DC
CH2: VOUT, 2V/Div, DC
CH3: IOUT, 0.5A/Div, DC
TIME:5ms/Div
CH1: VIN, 2V/Div, DC
CH2: VOUT, 2V/Div, DC
CH3: IOUT, 0.5A/Div, DC
TIME:20ms/Div
Turn On Response
Turn Off Response
VIN
VEN
1
1
VOUT
VOUT
2
3
2
IOUT
IOUT
3
VIN =5V, RLOAD =30W, CIN =1mF/MLCC,
COUT =100mF/Electrolytic, SS open
VIN =5V, RLOAD =30W, CIN =1mF/MLCC,
COUT =100mF/Electrolytic, SS open
CH1: VEN, 5V/Div, DC
CH2: VOUT, 2V/Div, DC
CH3: IOUT, 0.5A/Div, DC
TIME:0.5ms/Div
CH1: VEN, 5V/Div, DC
CH2: VOUT, 2V/Div, DC
CH3: IOUT, 0.5A/Div, DC
TIME:1ms/Div
