C 091 A
Male cable connector,
screw locking,
right-angled
Description
Drawing
No. of
cont.
Part Number solder termination
Part Number
Contact plating
silver
Contact plating
Crimp termination 1)
gold 2)
2
T 3200 005
T 3260 005
T 3300 005
T 3360 005
T 3356 005
T 3400 005
T 3475 005
T 3484 005
T 3504 005
T 3635 005
T 3650 005
–
–
Male cable connector,
right-angled,
for cable diameter 4-6 mm,
termination: solder or crimp,
contact plating: silver or gold.
3 3)
4 3)
5
5 S 3)
6 3)
7
7 3)
8 3)
12
14
T 3260 058 4)
T 3300 058 4)
T 3360 058
T 3356 058 4)
T 3400 058
T 3475 058 4)
T 3484 058 4)
T 3504 058 4)
T 3635 058
T 3650 058
T 3260 055
T 3300 055
T 3360 055
T 3356 055
T 3400 055
T 3475 055
T 3484 055
T 3504 055
–
64
(2.520)
17
(DIA.670)
–
1)
Please order crimp contacts separately, see page 43
2) See remark page 6
3) Contact order for DIN EN 60 130-9
4) Available upon request.
6)
6)
Assembly instructions
Assembly instructions
male cable connector, cable diameter 4-6 mm
male cable connector, cable diameter 4-6 mm or 6-8 mm
tightening torque 1Nm
tightening torque 0,3Nm
tightening torque 0,3Nm
5)
5)
tightening torque 0,4Nm
tightening torque 0,4Nm
6)
Assembly instructions
male cable connector, right-angled, can be keyed to 8 angle positions
tightening torque 0,4Nm
fold back
shielding
5)
Solder version only
6) Assembly Instructions please refer to page 46, conneting instructions
8
