A43E16161
The clock signal must also be asserted at the same time.
2. After VDD reaches the desired voltage, a minimum pause
of 200 microseconds is required with inputs in NOP
condition.
3. All banks must be precharged now.
4. Perform a minimum of 2 Auto refresh cycles to stabilize
the internal circuitry.
5. Perform a MODE REGISTER SET cycle to program the
CAS latency, burst length and burst type as the default
value of mode register is undefined.
Device Operations
Clock (CLK)
The clock input is used as the reference for all SDRAM
operations. All operations are synchronized to the positive
going edge of the clock. The clock transitions must be
monotonic between VIL and VIH. During operation with CKE
high all inputs are assumed to be in valid state (low or high)
for the duration of set up and hold time around positive edge
of the clock for proper functionality and ICC specifications.
At the end of one clock cycle from the mode register set
cycle, the device is ready for operation.
Clock Enable (CKE)
When the above sequence is used for Power-up, all the
out-puts will be in high impedance state. The high
impedance of outputs is not guaranteed in any other
power-up sequence.
The clock enable (CKE) gates the clock onto SDRAM. If
CKE goes low synchronously with clock (set-up and hold
time same as other inputs), the internal clock is suspended
from the next clock cycle and the state of output and burst
address is frozen as long as the CKE remains low. All other
inputs are ignored from the next clock cycle after CKE goes
low. When all banks are in the idle state and CKE goes low
synchronously with clock, the SDRAM enters the power
down mode from the next clock cycle. The SDRAM remains
in the power down mode ignoring the other inputs as long as
CKE remains low. The power down exit is synchronous as
the internal clock is suspended. When CKE goes high at
least “tSS + 1 CLOCK” before the high going edge of the
clock, then the SDRAM becomes active from the same clock
edge accepting all the input commands.
cf.) Sequence of 4 & 5 may be changed.
Mode Register Set (MRS)
The mode register stores the data for controlling the various
operation modes of SDRAM. It programs the CAS latency,
addressing mode, burst length, test mode and various
vendor specific options to make SDRAM useful for variety of
different applications. The default value of the mode register
is not defined, therefore the mode register must be written
after power up to operate the SDRAM. The mode register is
written by asserting low on
,
,
,
(The
WE
CS RAS CAS
SDRAM should be in active mode with CKE already high
prior to writing the mode register). The state of address pins
Bank Select (BA)
A0~A10/AP,
BA
in
the
same
cycle
as
This SDRAM is organized as 2 independent banks of
1,048,576 words X 16 bits memory arrays. The BA inputs is
,
,
,
WE
CS RAS CAS
going low is the data written in the
latched at the time of assertion of
and
to select
CAS
RAS
mode register. One clock cycle is required to complete the
write in the mode register. The mode register contents can
be changed using the same command and clock cycle
requirements during operation as long as all banks are in the
idle state. The mode register is divided into various fields
depending on functionality. The burst length field uses
A0~A2, burst type uses A3, addressing mode uses A4~A6,
A7~A8, A10/AP, BA are used for vendor specific options or
test mode. And the write burst length is programmed using
A7~A9, A10/AP, BA must be set to low for normal SDRAM
operation.
the bank to be used for the operation. The bank select BA is
latched at bank activate, read, write mode register set and
precharge operations.
Address Input (A0 ~ A10/AP)
The 19 address bits required to decode the 1,048,576 word
locations are multiplexed into 11 address input pins
(A0~A10/AP). The 11 bit row address is latched along with
, BA during bank activate command. The 9 bit column
RAS
Refer to table for specific codes for various burst length,
addressing modes and CAS latencies. BA have to be set to
“0” to enter the Mode Register.
address is latched along with
or write command.
,
, BA during read
WE
CAS
NOP and Device Deselect
Extended Mode Register (EMRS)
The Extended Mode Register controls functions beyond
those controlled by the Mode Register. These additional
functions are unique to AMIC’s Low Power SDRAM and
includes a Partial-Array Self Refresh field (PASR) and
Output Drive Strength. The Extended Mode Register is
programmed via the Mode Register Set command (BA=1)
and retains the stored information until it is programmed
again or the device loses power. The Extended Mode
Register must be programmed with A8 through A10 set to
“0”. The Extended Mode Register must be loaded when all
banks are idle and no bursts are in progress, and the
controller must wait the specified time initiating any
subsequent operation. Violating either of these requirements
results in unspecified operation.
When
,
and
are high, the SDRAM
WE
RAS
CAS
performs no operation (NOP). NOP does not initiate any new
operation, but is needed to complete operations which
require more than single clock like bank activate, burst read,
auto refresh, etc. The device deselect is also a NOP and is
entered by asserting
high.
high disables the
CS
CS
command decoder so that
the address inputs are ignored.
,
and , and all
WE
RAS CAS
Power-Up
The following sequence is recommended for POWER UP
1. Power must be applied to either CKE and DQM inputs to
pull them high and other pins are NOP condition at the
inputs before or along with VDD (and VDDQ) supply.
