The FRC# and FWC# inputs allow Add-On logic to
reset the PCI to Add-On or Add-On to PCI FIFO flags.
The FIFO flags can always be reset with software
through the Add-On General Control/Status Register
(AGCSTS) or the Bus Master Control/Status Register
(MCSR), but these hardware inputs are useful for
designs which do no implement a CPU on the Add-On
card. Asserting the FRC# input resets the PCI to Add-
On FIFO. Asserting the FWC# input re-sets the Add-
On to PCI FIFO.
used, this must be considered in the interrupt service
routine.
8-Bit and 16-Bit FIFO Add-On Interfaces
The S5935 FIFO may also be used to transfer data
between the PCI bus and 8-bit or 16-bit Add-On inter-
faces. This can be done using FIFO advance
conditions or the S5935 MODE input pin.
The FIFO may be used as an 8-bit or 16-bit wide
FIFO. To use the FIFO as an 8-bit interface, the
advance condition should be set for byte 0 (no data is
transferred in the upper 3 bytes). To use the FIFO as a
16-bit interface, the advance condition should be set
for byte 1 (no data is transferred in the upper 2 bytes).
This allows a simple Add-On bus interface, but it has
the disadvantage of not efficiently utilizing the PCI bus
bandwidth because the host is forced to perform 8-bit
or 16-bit accesses to the FIFO on the PCI bus. This is
the only way to communicate with an 8-bit Add-On
through the FIFO without additional logic to steer byte
lanes on the Add-On data bus. Pass-Thru mode is
more suited to 8-bit Add-On interfaces.
The AMREN and AMWEN inputs allow Add-On logic
to individually enable and disable bus mastering for
the PCI to Add-On and Add-On to PCI FIFO. These
inputs override the Bus Master Control/Status Register
(MCSR) bus master enable bits. The S5935 may re-
quest the PCI bus for the PCI to Add-On FIFO when
AMREN is asserted and may request the PCI bus for
the Add-On to PCI FIFO when AMWEN is asserted. If
AMREN or AMWEN is deasserted, the S5935
removes its PCI bus request and gives up control of
the bus.
AMREN and AMWEN are useful for Add-Ons with
external FIFOs cascaded into the S5935. For PCI bus
master write operations, the entire S5935 Add-On to
PCI FIFO and the external FIFO may be filled before
enabling bus mastering, providing a single long burst
write rather than numerous short bursts.
Implementing a 16-bit wide FIFO is a reasonable solu-
tion, but to avoid wasting PCI bus bandwidth, the best
method is to allow the PCI bus and the FIFO to oper-
ate with 32-bit data. The S5935 can assemble or
disassemble 32-bit quantities for the Add-On interface.
This is possible through the MODE pin. When MODE
is low, the Add-On data bus is 32-bits. When MODE is
high, the Add-On data bus is 16-bits. When MODE is
configured for 16-bit operation, BE3# becomes ADR1.
In some applications, the amount of data to be trans-
ferred is not known. During read operations, the
S5935, attempting to fill its PCI to Add-On FIFO, may
access up to eight memory locations beyond what is
required by the Add-On before it stops. In this situa-
tion, AMREN can be deasserted to disable PCI reads,
and then FRC# can be asserted to flush the unwanted
data from the FIFO.
With the FIFO direct access signals (RDFIFO# and
WRFIFO#), the MODE pin must reflect the actual Add-
On data bus width. With MODE = 16-bits, the S5935
automatically takes two consecutive, 16-bit Add-On
writes to the FIFO and assembles a 32-bit value. FIFO
reads operate in the same manner. Two consecutive
Add-On reads empty the 32-bit FIFO register. The 16-
bit data bus is internally steered to the lower and upper
words of the 32-bit FIFO register.
FIFO Generated Add-On Interrupts
For Add-On initiated bus mastering, the S5935 may be
configured to generate interrupts to the Add-On inter-
face for the following situations:
- Read transfer count reaches zero
- Write transfer count reaches zero
One consideration needs to be taken when using the
FIFO direct access signals and letting the S5935 do
byte lane steering internally. The default condition
used to advance the FIFO is byte 0. This must be
changed to byte 2 or 3. When MODE is configured for
a 16-bit Add-On bus, the first 16-bit cycle to the FIFO
always accesses the low 16-bits. If the FIFO advance
condition is left at byte 0, the FIFO advances after the
first 16-bit cycle and the data in the upper 16-bits is
directed to the next FIFO location, shifting the data.
- An error occurred during the bus master
transaction
The interrupt is posted to the Add-On interface with
the IRQ# output. A high-to-low transition on this output
indicates an interrupt condition. Because there is a
single interrupt output and multiple interrupt condi-
tions, the Add-On Interrupt Control/Status Register
(AINT) must be read to determine the interrupt source.
This register is also used to clear the interrupt, return-
ing IRQ# to its high state. If mailbox interrupts are also
