Cyclone Device Handbook, Volume 1
Features
The Cyclone device family offers the following features:
■
■
■
■
■
■
■
■
■
■
■
■
2,910 to 20,060 LEs, see
Table 1–1
Up to 294,912 RAM bits (36,864 bytes)
Supports configuration through low-cost serial configuration device
Support for LVTTL, LVCMOS, SSTL-2, and SSTL-3 I/O standards
Support for 66- and 33-MHz, 64- and 32-bit PCI standard
High-speed (640 Mbps) LVDS I/O support
Low-speed (311 Mbps) LVDS I/O support
311-Mbps RSDS I/O support
Up to two PLLs per device provide clock multiplication and phase
shifting
Up to eight global clock lines with six clock resources available per
logic array block (LAB) row
Support for external memory, including DDR SDRAM (133 MHz),
FCRAM, and single data rate (SDR) SDRAM
Support for multiple intellectual property (IP) cores, including
Altera
®
MegaCore
®
functions and Altera Megafunctions Partners
Program (AMPP
SM
) megafunctions.
Table 1–1. Cyclone Device Features
Feature
LEs
M4K RAM blocks (128
×
36 bits)
Total RAM bits
PLLs
Maximum user I/O pins
(1)
Note to
Table 1–1:
(1)
This parameter includes global clock pins.
EP1C3
2,910
13
59,904
1
104
EP1C4
4,000
17
78,336
2
301
EP1C6
5,980
20
92,160
2
185
EP1C12
12,060
52
239,616
2
249
EP1C20
20,060
64
294,912
2
301
