AS4C16M16SA
DQ0-DQ15
Input /
Output
Data I/O: The DQ0-15 input and output data are synchronized with the positive edges
of CLK. The I/Os are maskabled during Reads and Writes.
NC
-
No Connect: These pins should be left unconnected.
VDDQ
Supply
DQ Power: Provide isolated power to DQs for improved noise immunity.
( 3.3V 0.3V )
VSSQ
Supply
DQ Ground: Provide isolated ground to DQs for improved noise immunity.
( 0 V )
VDD
VSS
Supply
Supply
Power Supply: +3.3V 0.3V
Ground
