Agilent HSMx-A10x-xxxxx
PLCC-2 SMT LED
Product Brief
Features and Benefits
• Industry Standard PLCC-2 SMT
package
– No change in existing board
layout, drop-in replacement for
the existing PLCC-2 SMT LEDs
• High brightness using AlInGaP and
InGaN dice technologies
– Only supplier using TS AlInGaP
material
Background
The PLCC-2 SMT LED products
with a viewing angle of 120° is
ideal for instruments/switch/icon
backlighting. Its external reflec-
tor makes easy coupling with
light pipe/light guide for an even-
larger area backlighting. The
package design coupled with
careful selection of component
materials allow these products
to perform with high reliability in
a larger temperature range -40°C
to 100°C. The high reliability
feature is crucial to Automotive
Interior and Indoor ESS.
An industry leader in high
brightness LED technology,
Agilent Technologies offers a
wide range of surface-mount
(SMT) LEDs, including Subminia-
ture lamps, ChipLEDs and High
flux LEDs. As more applications
demand SMT LEDs, we have
introduced the Agilent PLCC-2
SMT LEDs. These new products
deliver top emission in the
industry-standard PLCC-2
package.
• Available in multiple colors
– Broad range of colors: Red, Red-
Orange, Orange, Amber, Yellow-
Green, Emerald Green, Green,
Cyan and Blue
• Super wide viewing angle at 120°
– Well-suited for backlighting
applications
• High volume, high reliability
– Cost effective solution
About the products
• Compatible with both IR and TTW
soldering process
This package is also designed to
be compatible with both
IR-solder reflow and
This surface-mount LED comes
in PLCC-2 standard package
dimension. It has a substrate
made up of a molded plastic
reflector sitting on top of a bent
lead frame. The die is attached
within the reflector cavity and
the cavity is encapsulated by an
Agilent proprietary epoxy blend.
• Black reflector surface
– for reduce contrast in ESS
through-the-wave soldering.
• High brightness performance – only
PLCC-2 SMT LED supplier offering
TS AlInGaP material
The new Agilent TLED will carry
the part number HSMx-A10x-
xxxxx.
AGILENT [ AGILENT TECHNOLOGIES, LTD. ]
