Agilent HLMP-Pxxx
Subminiature LED Lamps
Data Sheet
Features
• Subminiature flat top package
– ideal for backlighting and light
piping applications
• Subminiature dome package
– diffused dome for wide viewing
angle
HLMP-Pxxx Series, HLMP-Qxxx Series
HLMP-6xxx Series, HLMP-70xx Series
– nondiffused dome for high
brightness
Description
Flat Top Package
Resistor Lamps
The HLMP-6xxx Series 5 volt
subminiature lamps with built in
current limiting resistors are for
use in applications where space
is at a premium.
• TTL and LSTTL compatible 5 volt
resistor lamps
The HLMP-Pxxx Series flat top
lamps use an untinted, non-
diffused, truncated lens to
provide a wide radiation pattern
that is necessary for use in
backlighting applications. The
flat top lamps are also ideal for
use as emitters in light pipe
applications.
• Available in six colors
• Ideal for space limited
applications
Lead Configurations
• Axial leads
All of these devices are made by
encapsulating LED chips on
axial lead frames to form molded
epoxy subminiature lamp
• Available with lead configurations
for surface mount and through
hole PC board mounting
Dome Packages
packages. A variety of package
configuration options is avail-
able. These include special
surface mount lead configura-
tions, gull wing, yoke lead or
Z-bend. Right angle lead bends
at 2.54 mm (0.100 inch) and
5.08 mm (0.200 inch) center
spacing are available for through
hole mounting. For more
The HLMP-6xxx Series dome
lamps for use as indicators use a
tinted, diffused lens to provide a
wide viewing angle with a high
on-off contrast ratio. High
brightness lamps use an
untinted, nondiffused lens to
provide a high luminous
intensity within a narrow
radiation pattern.
information refer to Standard
SMT and Through Hole Lead
Bend Options for Subminiature
LED Lamps data sheet.
