Regulatory Compliance Table
Feature
Test Method
Performance
Electrostatic Discharge (ESD) to MIL-STD-883C
Meets Class 1 (<1999 Volts)
the Electrical Pins
Method 3015.4
Withstand up to 1500 V applied between electrical pins.
Electrostatic Discharge (ESD) to Variation of
Typically withstand at least 25 kV without damage when the Duplex SC
Connector Receptacle is contacted by a Human Body Model probe.
the Duplex SC Receptacle
IEC 801-2
Electromagnetic Interference
(EMI)
FCC Class B
Typically provide a 13 dB margin (with duplex SC package) or a 9 dB margin
(with duplex ST package) to the noted standard limits when tested at a certified
test range with the transceiver mounted to a circuit card without a chassis
enclosure.
CENELEC CEN55022
Class B (CISPR 22B)
VCCI Class 2
Immunity
Variation of
IEC 801-3
Typically show no measurable effect from a 10 V/m field swept from 10 to 450
MHz applied to the transceiver when mounted to a circuit card without a
chassis enclosure.
Electromagnetic Interference (EMI)
In all well-designed chassis, two
Transceiver Reliability and
Most equipment designs utilizing 0.5" holes for ST connectors to
Performance Qualification Data
The 1 x 9 transceivers have
passed Agilent reliability and
performance qualification
testing and are undergoing
ongoing quality monitoring.
Details are available from your
Agilent sales representative.
these high speed transceivers
from Agilent will be required to
protrude through will provide
4.6 dB more shielding than one
meet the requirements of FCC in 1.2" duplex SC rectangular
the United States, CENELEC
EN55022 (CISPR 22) in Europe
and VCCI in Japan.
cutout. Thus, in a well-designed
chassis, the duplex ST 1 x 9
transceiver emissions will be
identical to the duplex SC 1 x 9
transceiver emissions.
200
These transceivers are manufac-
tured at the Agilent Singapore
location which is an ISO 9002
certified facility.
3.0
180
1.5
Immunity
Equipment utilizing these
transceivers will be subject to
radio-frequency electromagnetic
fields in some environments.
These transceivers have a high
immunity to such fields.
160
2.0
2.5
3.5
Accessory Duplex SC Connectored
Cable Assemblies
Agilent recommends for optimal
coupling the use of flexible-body
duplex SC connectored cable.
140
120
100
3.0
3.5
tr/f - TRANSMITTER
OUTPUT OPTICAL
RISE/FALL TIMES - ns
For additional information
1200
1300
1320
1340
1360 1380
regarding EMI, susceptibility,
ESD and conducted noise testing
procedures and results on the
1 x 9 Transceiver family, please
refer to Applications Note 1075,
Testing and Measuring Electro-
magnetic Compatibility
l
C - TRANSMITTER OUTPUT OPTICAL
CENTER WAVELENGTH - nm
Accessory Duplex ST Connectored
Cable Assemblies
Agilent recommends the use of
Duplex Push-Pull connectored
cable for the most repeatable
optical power coupling
performance.
HFBR-5803 FDDI TRANSMITTER TEST RESULTS
OF lC Dl AND tr/f ARE CORRELATED AND
,
COMPLY WITH THE ALLOWED SPECTRAL WIDTH
AS A FUNCTION OF CENTER WAVELENGTH FOR
VARIOUS RISE AND FALL TIMES.
Performance of the HFBR-510X/
520X Fiber Optic Transceivers.
Figure 9. Transmitter Output Optical Spectral
Width (FWHM) vs. Transmitter Output Optical
Center Wavelength and Rise/Fall Times.
9
