Absolute Maximum Ratings
Stresses in excess of the absolute maximum ratings can cause catastrophic damage to the device. Limits apply to each parameter in
isolation, all other parameters having values within the recommended operating conditions. It should not be assumed that limiting values
of more than one parameter can be applied to the product at the same time. Exposure to the absolute maximum ratings for extended
periods can adversely affect device reliability.
Parameter
Symbol
Min.
Typ.
Max.
Unit
Reference
Storage Temperature
TS
-40
+100
°C
Lead Soldering Temperature
Lead Soldering Time
Supply Voltage
TSOLD
tSOLD
VCC
VI
+260
10
°C
sec.
V
-0.5
-0.5
7.0
VCC
1.4
50
Data Input Voltage
Differential Input Voltage
Output Current
V
VD
V
Note 1
IO
mA
Recommended Operating Conditions
Parameter
Symbol
Min.
Typ.
Max.
Unit
Reference
Ambient Operating Temperature
HFBR-5803/5803T
TA
0
+70
°C
Note A
Note B
HFBR-5803A/5803AT
Supply Voltage
TA
VCC
-10
3.135
+85
3.5
°C
V
VCC
4.75
5.25
V
V
V
W
Data Input Voltage - Low
VIL - VCC
VIH - VCC
RL
-1.810
-1.165
-1.475
-0.880
Data Input Voltage - High
Data and Signal Detect Output Load
50
Note 2
Notes:
A. Ambient Operating Temperature corresponds to transceiver case temperature of 0°C mininum to +85 °C maximum with necessary airflow applied.
Recommended case temperature measurement point can be found in Figure 2.
B. Ambient Operating Temperature corresponds to transceiver case temperature of -10 °C mininum to +100 °C maximum with necessary airflow applied.
Recommended case temperature measurement point can be found in Figure 2.
Transmitter Electrical Characteristics
(HFBR-5803/5803T: T = 0°C to +70°C, V = 3.135 V to 3.5 V or 4.75 V to 5.25 V)
A
CC
(HFBR-5803A/HFBR-5803AT: T = -10°C to +85°C, V = 3.135 V to 3.5 V or 4.75 V to 5.25 V)
A
CC
Parameter
Symbol
Min.
Typ.
Max.
Unit
Reference
Supply Current
ICC
133
175
mA
Note 3
Power Dissipation
at VCC = 3.3 V
at VCC = 5.0 V
PDISS
PDISS
IIL
0.45
0.76
-2
0.6
W
W
0.97
Data Input Current - Low
-350
µA
µA
Data Input Current - High
IIH
18
350
12
