ADLS15PC PC/104-Plus
Intel® Atom™ CPU 1.1GHz - 1.60GHz
TECHNICAL SPECIFICATIONS - ADLS15PC
FEATURE
FUNCTION
REMARKS
OPTIONS
[processor] / [memory] / [cooling type]
Z510 / 2GB / Active: 1.54A @ +5VDC, typical*
Z510 / 2GB / Passive: 1.56A @ +5VDC, typical*
*Typical numbers are based on a standard
configuration and are for reference only.
Actual vaules may vary based on applicaton,
operating system, peripherals and memory.
Please contact Sales with questions.
Power consumption
Z530 / 2GB / Active: 1.78A @ +5VDC, typical*
Z530 / 2GB / Passive: 1.80A @ +5VDC, typical*
Provided CPU is kept below 90°C at all
times and the installation has sufficient
thermal path to dissipate
Operating Temperature
(typ. ambient)
-25ºC - +70ºC
*Extended Temp -optional
MTBF
219,000 Hours
Calculation method: MIL-HDBK-217F
Same features as LAN1
Dimensions
3.6” x 3.8” (90mm x 96mm)
Weight (gr)
86 g
*Data subject to change without notice.
ADL Germany: Eiserfelder Straße 316 | D-57080 Siegen, Germany
ADL Corporate: 4411 Morena Blvd. Suite 101 | San Diego, CA 92117-4345
T: +49 (0) 271.250.810.0
F: +49 (0) 271.250.810.20
T: 858.490.0597
F: 858.490.0599
sales@adl-europe.com
www.adl-europe.com
sales@adl-usa.com
www.adl-usa.com
ADL [ ADVANCED DIGITAL LOGIC, INC. ]
