ADLQM87HD 3.5" SBC
4th Generation Intel® Core™ Quad / DC i5 / i7
ORDERING INFORMATION
ITEM CODE
PART #
DESCRIPTION
3.5-inch Board
ADLQM87HD-i7-4700EQ
ADLQM87HD-i5-4400E
294756
294758
4th Generation Intel Core i7 2.4GHz 4C, 6M, 47W
4th Generation Intel Core i5 2.7GHz 2C, 3M, 37W
Memory
DDR3L-DRAM4096-1600
DDR3L-DRAM8192-1600
DDR3L-DRAM4096-1600-EX
DDR3L-DRAM8192-1600-EX
997600
997601
997602
997604
DDR3L-1600MHz 4GB Standard Temperature
DDR3L-1600MHz 8GB Standard Temperature
DDR3L-1600MHz 4GB Extended Temperature
DDR3L-1600MHz 8GB Extended Temperature
Other memory options available
Options and Accessories
ADL-ET
290000
294875
299941
299942
Extended Temp Screen (-40º to +85º C)
Standard Cable kit for ADLQM87HD
Galvanically Isolated RS232 COM
Galvanically Isolated RS485 COM
ADLQM87HD-CK
ADLCOM-ISOL1
ADLCOM-ISOL2
Thermal Solutions
ADLQM87HD-SPREADER
ADL35-BBHS
294863
294152
294154
294156
Chassis / Bulkhead mount heat spreader for ADLQM87HD For Quad and Dual Core variants
Large Heatsink for bench testing; requires ADL35-LFAN
Large Fan for ADL35-BBHS
ADL35-LFAN
ADL35-SOSET
Stand-Off Set for ADL35-BBHS, M3, 6mm, 37mm
*Data subject to change without notice.
