ADLE3800PC PCIe/104 SBC
Intel® E3800 Series SoC Processors
ORDERING INFORMATION
ITEM CODE
PART #
DESCRIPTION
PCIe/104 Board
ADLE3800PC-E3845
ADLE3800PC-E3827
292800
292802
Intel E3845; QC, 1.91 GHz, 2MB, 10W TDP
Intel E3827; DC, 1.75 GHz, 1MB, 8W TDP
Memory
4GB DDR3L-1600
8GB DDR3L-1600
4GB DDR3L-1600-EX
8GB DDR3L-1600-EX
997600
997601
997602
997604
DDR3L-1600MHz 4GB Standard Temperature
DDR3L-1600MHz 8GB Standard Temperature
DDR3L-1600MHz 4GB Extended Temperature
DDR3L-1600MHz 8GB Extended Temperature
Options and Accessories
ADL-ET
290000
807707
807706
807709
Extended Temp Screen (-40º to +85º C)
BGA underfill req’d for –40C operation
Conformal Coating
UNDERFILL
COATING
UNDERFILL / BONDING / COATING
Underfilling, Bonding, and Conformal Coating
Thermal Solutions
ADLE3800PC-SP0600
ADLE3800PC-SP1000
ADLE3800PC-LP
292806
292808
292810
292812
0.600” Heat Spreader
1.000” Heat Spreader
Low Profile Passive Heatsink
2” x 2” Fansink
ADLE3800PC-FANSINK
*Data subject to change without notice.
