ADSP-BF542/ADSP-BF544/ADSP-BF547/ADSP-BF548/ADSP-BF549
ESD SENSITIVITY
ESD (electrostatic discharge) sensitive device.
Charged devices and circuit boards can discharge
without detection. Although this product features
patented or proprietary protection circuitry, damage
may occur on devices subjected to high energy ESD.
Therefore, proper ESD precautions should be taken to
avoid performance degradation or loss of functionality.
PACKAGE INFORMATION
The information presented in Figure 9 and Table 24 provides
information related to specific product features. For a complete
listing of product offerings, see the Ordering Guide on
Page 100.
a
ADSP-BF54x(M)
tppZ-cc
vvvvvv.x-q n.n
# yywwcountry_of_origin
B
Figure 9. Product Information on Package
Table 24. Package Information
Brand Key
Description
BF54x
x = 2, 4, 7, 8 or 9
(M)
Mobile DDR Indicator (optional)
Temperature Range
Package Type
t
pp
Z
RoHS Compliant part
See Ordering Guide
Assembly Lot Code
Silicon Revision
cc
vvvvvv.x-q
n.n
#
RoHS Compliant Designation
Date Code
yyww
Rev. C
|
Page 41 of 100
|
February 2010
