Amplifiers for Automotive Applications
With over 45 years of experience in signal processing
and the industry’s leading portfolio, ADI provides design
engineers with the robust amplifier products and
technical support to build any automotive applications.
ADI’s technologies are used to address the most
challenging signal chain requirements in advanced safety,
infotainment, power-train, and body/chassis electronics
systems for electric, hybrid, and fossil fuel powered
vehicles worldwide.
AIRBAG SYSTEMS
AUDIO SYSTEMS
SECURITY SYSTEMS
ENGINE MANAGEMENT
TIRE PRESSURE
ELECTRONIC POWER STEERING
ADI’s automotive grade amplifiers are identified by the “W”
suffix immediately after the part number. These products
are qualified for automotive applications and meet or
exceed the rigorous requirements of the automotive
industry.
BATTERY MANAGEMENT
RADAR FOR
DRIVER ASSISTANCE
ELECTRO HYDRAULIC BRAKES
TRANSMISSION
ADAPTIVE SUSPENSION
Application
Recommended Amplifiers
Part Description
Key Amplifier Characteristics
Precision: AD8601WARTZ-R7, AD8601WARTZ-RL,
AD8601WDRTZ-REEL
DigiTrim rail-to-rail input and output single amplifier
with very low offset voltage
Precision: AD8617WARMZ-REEL, AD8617WARZ-R7,
AD8617WARZ-RL
Low cost, micropower, low noise, CMOS, rail-to-rail
input/output op amp
Precision: AD8628WARTZ-R7, AD8628WARTZ-RL,
AD8628WARZ-R7, AD8628WARZ-RL, AD8628WAUJZ-R7,
AD8628WAUJZ-RL
Zero drift, single-supply, rail-to-rail input/
output operational amplifier
Zero drift, single-supply, rail-to-rail, input/
output operational amplifier
Automotive sensing
Auto-zero, low offset voltage and low offset voltage
Precision: AD8629WARZ-R7, AD8629WARZ-RL
Precision: AD8630WARZ-R7, AD8630WARZ-RL
Quad, zero drift, single-supply,
rail-to-rail operational amplifier
Precision: AD8646WARMZ-R7, AD8646WARMZ-RL,
AD8646WARZ-R7, AD8646WARZ-RL
24 MHz, rail-to-rail, dual amplifier
Precision: AD8648WARUZ, AD8648WARUZ-RL
Precision: AD8656WARMZ-REEL
24 MHz, rail-to-rail, quad amplifier
Low noise, precision CMOS dual amplifier
High speed: ADA4851-1WYRJZ-R7,
ADA4851-2WYRMZ-R7, ADA4851-4WYRUZ-R7
Low cost, rail-to-rail output op amp
High speed: ADA4853-3WYRUZ-R7
Ultralow power, rail-to-rail output op amp
Infortainment
and vision ADAS
Video amplifiers
High speed: ADA4891-1WARJZ-R7,
ADA4891-2WARMZ-R7, ADA4891-4WARUZ-R7
Low cost, CMOS, rail-to-rail op amp
Low cost
High speed: AD8040WARUZ-R7,
AD8028WARMZ-R7, AD8065WARTZ-R7
Rail-to-rail, FET input
Wide bandwidth, low power
Differential amps
Advanced driver
assistance (ADAS)
High speed: AD8132WARMZ-R7, AD8137WYCPZ-R7 Single ended input or differential input, differential output
Precision: AD8628WARTZ-R7, AD8628WARTZ-RL,
Zero-drift, single-supply, rail-to-rail input/
AD8628WARZ-R7, AD8628WARZ-RL, AD8628WAUJZ-R7,
output operational amplifier
AD8628WAUJZ-RL
Zero-drift, single-supply, rail-to-rail, input/
Precision: AD8629WARZ-R7, AD8629WARZ-RL
output operational amplifier
Quad, zero-drift, single-supply, rail-to-rail
Precision: AD8630WARZ-R7, AD8630WARZ-RL
Pressure sensing
In antilock braking
systems (ABS)
operational amplifier
Low offset, low noise
Precision: AD8601WARTZ-R7, AD8601WARTZ-RL,
AD8601WDRTZ-REEL
DigiTrim rail-to-rail input and output single amplifier
with very low offset voltage
Dual, low cost, low noise, CMOS rail-to-rail output
operational amplifier
Precision: AD8692WARMZ-REEL
Quad, low cost, low noise, CMOS rail-to-rail output
operational amplifier
Precision: AD8694WARUZ, AD8694WARUZ-REEL
For more information in automotive applications, visit automotive.analog.com.
www.analog.com/opamps
