(1) Auto Mode Luminance Noise Reduction Mode Settings (AYABN)
Sets whether or not to use the luminance absolute noise reduction mode in the auto mode luminance noise
follow-up status (YDTO2 = 1).
Table F2-1-8 (3) Auto Mode Luminance Noise Reduction Mode Settings (YABN = 0)
YDTO2
AYABN
Luminance noise reduction mode
0
1
X
0
YABN dependent
YABN dependent
Absolute noise reduction mode (equivalent to
YABN = 1 operation)
1
1
(2) Auto Mode Chrominance Noise Reduction Mode Settings (ACABN)
Sets whether or not to use the chrominance absolute noise reduction mode in the auto mode chrominance noise
follow-up status (CDTO2 = 1).
Table F2-1-8 (4) Auto Mode Chrominance Noise Reduction Mode Settings (CABN = 0)
CDTO2
ACABN
Chrominance Noise Reduction Mode
0
1
X
0
CABN dependent
CABN dependent
Absolute noise reduction mode (equivalent to
CABN = 1 operation)
1
1
(3) Auto Mode Luminance Noise Convergence Level Settings (AYNS[1:0])
Sets whether or not to use the luminance noise convergence level automatic setting in the auto mode luminance
noise follow-up status (YDTO2 = 1).
When AMM = 0, noise reduction stops with YDTO1 = 0, so the luminance noise convergence level is ignored.
Table F2-1-8 (5) Auto Mode Luminance Noise Convergence Level Settings
AYNS
YBDTO
YDTO1
YDTO2
Luminance noise convergence level
[1]
0
1
[0]
X
0
YNS[5:0]
YNS[5:0] + YMAXO[4:0](max:3Fh)
Smaller of YMAXO[4:0] x 3(max:3Fh) and YNS[5:0]
YNS[5:0]
0
1
1
X
X
X
X
0
1
1
1
X
0
1
X
X
0
YNS[5:0]
YNS[5:0] + YMAXO[4:0](max:3Fh)
Larger of YMAXO[4:0] x 3(max:3Fh) and YNS[5:0]
1
1
