FEDL87V2107-01
OKI Semiconductor
ML87V2107
Table R2-3-3 (1) Luminance Noise Reduction Motion Compensation Mode Setting
YNRM
Luminance motion decision noise processing (Motion compensation)
0
(Non-linear filter detection noise) × (Attenuation coefficient)
1
Fix to 0. (Decision without noise)
Table R2-3-3 (2) Chrominance Noise Reduction Motion Compensation Mode Setting
CNRM
Chrominance motion decision noise processing (Motion compensation)
(Non-linear filter detection noise) × (Attenuation coefficient)
Fix to 0. (Decision without noise)
0
1
Table R2-3-3 (3) Luminance Adaptive Noise Reduction Mode Settings
YFAM
Luminance adaptive noise reduction mode
Without adaptive margin (weak NR, few afterimages)
With adaptive margin (strong NR, many afterimages)
0
1
Table R2-3-3 (4) Chrominance Adaptive Noise Reduction Mode
CFAM
Chrominance adaptive noise reduction mode
Without adaptive margin (weak NR, few afterimages)
With adaptive margin (strong NR, many afterimages)
0
1
Table R2-3-3 (5) Luminance Absolute Noise Mode Setting
YABN
Luminance mode
Remarks
0
Normal noise mode
(Detection noise) × (Motion compensation attenuation coefficient)
(Detection noise)/2 + {(Detection noise) ×
(Motion compensation attenuation coefficient)}/2
1
Absolute noise mode
Table R2-3-3 (6) Chrominance Absolute Noise Mode Setting
CABN
Chrominance mode
Remarks
0
Normal noise mode
(Detection noise) × (Motion compensation attenuation coefficient)
(Detection noise)/2 + {(Detection noise) ×
(Motion compensation attenuation coefficient)}/2
1
Absolute noise mode
Table R2-3-3 (7) Auto Mode Luminance Absolute Noise Mode
Setting (Valid when NRAUTO=1)
AYABN
Noise follow-up state luminance mode
Normal noise mode
0
1
Absolute noise mode
Table R2-3-3 (8) Auto mode Chrominance Absolute Noise Mode
Setting (Valid when NRAUTO=1)
ACABN
Noise follow-up state chrominance mode
Normal noise mode
0
1
Absolute noise mode
117/152
