MITSUBISHI ICs (TV)
M52769FP
PLL-SPLIT VIF/SIF
INPUT SIGNAL
SG
50ohm Termination
1
2
fo=58.75MHz AM 20 KHz 77.8 % 90 dBµ
fo=58.75MHz 90 dBµ Cw
f1=58.75MHz 90 dBµ Cw
Mixed Signal
3
f2=Frequency Variable 70 dBµ Cw
fo=58.75MHz AM 20 KHz 77.8% Level Variable
fo=58.75MHz AM 20 KHz 14.0% Level Variable
fo=58.75 MHz 80 dBµ Cw
4
5
6
7
fo=58.75 MHz 110 dBµ Cw
8
fo=58.75 MHz Level Variable Cw
fo=Frequency Variable AM 20 KHz 77.8 % 90 dBµ
fo=Frequency Variable 90 dBµ Cw
f1=58.75MHz 90 dBµ Cw
9
10
Mixed Signal
f2=55.17MHz 80 dBµ Cw
f3=54.25MHz 80 dBµ Cw
11
12
fo=58.75MHz 87.5 % TV modulation Ten-step waveform
Sync Tip Level 90 dBµ
13
14
fo=54.25MHz 95 dBµ Cw
fo=54.25MHz 75 dBµ Cw
15
16
17
18
19
20
21
fo=4.5 MHz
fo=4.5 MHz
fo=4.5 MHz
fo=4.5 MHz
fo=4.5 MHz
90 dBµ FM 400 Hz ±25 KHz dev
Level Variable FM 400Hz ±25KHz dev
100 dBµ AM 400 Hz 30 %
Level Variable Cw
90 dBµ Cw
fo=54.25 MHz 90 dBµ Cw
fo=54.25 MHz Level Variable Cw
22
fo=4.5 MHz
90 dBµ FM 400 Hz ±75 KHz dev
MITSUBISHI
ELECTRIC
9
