717/719 SERIES

JMK Inc.

The 717 & 719 series filters provide superior wideband filter-

ing for Wye or Delta power configurations.

This series employs both differential mode and common

mode insertion loss.

Operating Voltage= 250/480 Vac

OperatingCurrentMax= 20,30 amp

Operating Frequency= 50-60Hz

Temperature Range= -20 to 50 deg. C

DieWithstand(Line to Case)= 1500V~ for 1 Min

DieWithstand (Line to Line)= 1500Vdc for 1 min

Leakage Current = 2.0 mA @ 250 VAC,560Hz

Discharge after 5.0 sec.= 34V Max

Agency Approvals = UL
