EN29LV160A
PRODUCT SELECTOR GUIDE
Product Number
EN29LV160A
Speed Option
Full Voltage Range: Vcc=2.7 – 3.6 V
-70
-90
Max Access Time, ns (tacc
Max CE# Access, ns (tce)
Max OE# Access, ns (toe)
)
70
70
30
90
90
35
BLOCK DIAGRAM
RY/BY#
Vcc
Vss
DQ0-DQ15 (A-1)
Block Protect Switches
Erase Voltage Generator
Input/Output Buffers
State
Control
WE#
Program Voltage
Generator
Command
Register
STB
Chip Enable
Output Enable
Logic
Data Latch
CE#
OE#
Y-Decoder
Y-Gating
STB
Vcc Detector
Timer
X-Decoder
Cell Matrix
A0-A19
