PAC5220
Power Application Controller
3. PRODUCT SELECTION SUMMARY
Table 3-1. Product Selection Summary
CONFIGURABLE
ANALOG FRONT
END
POWER
MANAGER
APPLICATION SPECIFIC
POWER DRIVERS
MICROCONTROLLER
PART
PIN
PRIMARY
NUMBER PKG
APPLICATION
SPI
56-pin
8x8
TQFN
3 LS (1A/1A)
11 3 HS (1A/1A)
2 OD (40V/40mA)
5.2-
Y
I2C
3 half bridge,
3-phase control
3
4
10
2
6
Int 50 32
8
28
Y
PAC5220
52V
UART
SWD
Notes: DIFF-PGA = differential programmable gain amplifier, GD = gate driver, HS = high-side , LS = low-side, OD = open-drain driver,
PGA = programmable gain amplifier, UHV = ultra-high-voltage.
4. ORDERING INFORMATION
Table 4-1. Ordering Information
PART NUMBER(2)
TEMPERATURE RANGE
PACKAGE
PINS
PACKING
PAC5220QS
-40°C to 105°C
TQFN88-56
56 + Exposed Pad
Tray
(1) See Product Selection Summary for product features for each part number.
(2) For the latest packaging and ordering information please see http://www.active-semi.com/ or contact us under sales@active-semi.com .
